主高压DC-DC转换器

DC-DC Icon主高压DC-DC转换器

In an electric vehicle, truck or bus there is both a high and low voltage power system. The HV system is supplied directly from the traction battery, supplying the motor and other large loads; the cabin and battery heater and A/C compressor. For commercial vehicles this extends to the air compressor and hydraulic pump. The low voltage 12 V or 24V system provides power for all other loads in the vehicle.

The LV battery is charged, and the loads supplied by the main DC-DC converter (1-3 kW) when the vehicle is in use, in the same way the alternator supplies the 12 V system in an ICE vehicle. When the vehicle is off the 12 V is maintained by the LV battery. For passenger vehicles the DC-DC converter is more commonly integrated within the OBC than being a standalone module.

Depending on the specific architecture either reinforced isolated or non-isolated supply rails are required to be created from the HV system voltage which makes the 1000 V input capable solutions from Power Integrations ideal.

参考设计

相关产品

Related Products
产品
数据手册
拓扑结构
电压等级
产品描述
Data Sheet 查看PDF
Topology Flyback, Secondary Side - FluxLink Regulated
Power Level 100 W
Description

适合汽车应用的集成750 V、900 V及1700 V开关和FluxLink反馈技术的恒压/恒流准谐振反激式开关IC

Data Sheet 查看PDF
Topology Non-Isolated Flyback, Buck/Boost/Buck-Boost
Power Level 850 mA
Description

适合汽车应用的集成了系统级保护的高能效开关IC,可实现低元件数的电源设计

Data Sheet 查看PDF
Topology 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped
Power Level
Description

汽车级单通道SiC MOSFET和IGBT门极驱动器,可提供高级有源钳位和加强绝缘
